Isuzu MU-X 2017-2020 Workshop Service Repair Manual PDF, First Generation

Isuzu MU-X 2017-2020 Service Repair Manual, First Generation

This is Isuzu’s own workshop manual for the updated first generation MU-X, the section by section manual Isuzu dealers use, as a PDF download. From the 3.0 4JJ1 and the 1.9 RZ4E-TC diesels to the automatic gearboxes, transfer case, brakes and body electrics, the procedures, torques and wiring diagrams are here across 7,911 pages.

Models:
Isuzu MU-X first generation, model codes UCR85, UCS85, UCR87 and UCS87, 4×2 and 4×4

Engines:
Diesel
3.0 4JJ1, with and without DPD
1.9 RZ4E-TC

Transmissions:
AWR6B45 6 speed automatic
TB-50LS 5 speed automatic
MVL 6 speed manual

Years: 2020, 2019, 2018, 2017

Format: PDF

Languages: English

Compatibility:
One zip of about 322 MB holding 80 PDF files. They open in any PDF reader on Windows, Mac, Linux, iPad or Android.

What is included in this workshop manual:
Each engine has its own set of sections, covering engine mechanical, fuel, cooling, lubrication, induction, exhaust, emission control, speed control and engine electrics, followed by engine control diagnosis. The chassis sections cover the front and rear suspension, wheels and tires, differentials, drive shafts and transfer case, brakes with ABS, the three gearboxes with their electrical controls, and power steering. The body sections cover heating and air conditioning, airbags and seat belts, lighting, wipers, instruments, doors, seats, locks, glass and trim, and the electrical wiring diagrams and connector locations close the set. And much more.

Special Features:
Official Isuzu service information, not an aftermarket summary
Separate sections for the 4JJ1 and RZ4E-TC engines
Component views with tightening torques
Electrical wiring diagrams and connector locations
Relay and fuse locations

Isuzu MU-X 2017-2020 4JJ1 Crankshaft PDF Download

Isuzu MU-X 2017-2020 Front Suspension PDF Download

Instant Download

Frequently Asked Questions

Is this for my MU-X?
It is for the first generation MU-X built from 2017 to 2020, with the 3.0 4JJ1 or the 1.9 RZ4E-TC diesel. For the second generation from 2021 see our Isuzu MU-X 2021-2024 manual.

Does it cover the 1.9 diesel?
Yes. The RZ4E-TC has its own engine mechanical, fuel, cooling, lubrication, induction, exhaust, emission and electrical sections.

Does it include the wiring diagrams?
Yes. There is a 102 page electrical wiring diagram book plus 75 pages of connector locations, relays and fuses.

How do I receive the manual after I pay?
A download link is sent as soon as your payment clears. The manual comes as one zip of about 322 MB holding 80 PDF files.

Have the new shape MU-X? The Isuzu MU-X 2021-2024 workshop manual covers the second generation, and every title is listed in the Isuzu workshop manual range.
