Subaru Forester Workshop Repair and Service Manual PDF 2009-2013

Subaru Forester SH 2009-2013 Workshop Repair, Service & Wiring Manual PDF

This Subaru Forester workshop repair manual PDF covers the SH generation built for 2009 to 2013, with the 2.0 and 2.5 litre petrol boxers, the 2.5 XT turbo and the 2.0 litre turbo diesel. It is Subaru’s own service manual in one 9,690 page PDF: maintenance schedules, removal and installation procedures, torque values, DTC diagnostics and the complete wiring system, everything needed for professional level repair and maintenance of the Subaru Forester.

Model:
Subaru Forester SH wagon (SH5, SH9 and SHD), all with full time AWD: 2.0 X, 2.0 XS, 2.5 X, 2.5 XS, 2.5 XT, 2.0 TD and 2.0 TD-E

Engines:
Petrol, Gasoline
2.0 litre DOHC EJ204, 148 PS
2.5 litre SOHC EJ253, 170 PS
2.5 litre DOHC turbo EJ255, 224 PS

Diesel:
2.0 litre DOHC turbo diesel EE20, 147 PS and 350 N·m

Transmissions:
4AT four speed automatic (petrol)
5MT five speed manual with single-range or dual-range transfer
6MT six speed manual (diesel)

Years: 2013, 2012, 2011, 2010, 2009

Format: PDF

Languages: English

Left and right hand drive covered.

Compatibility:
Windows 11, 10, 8, 7, Vista, XP, Mac, Linux, Android, iOS + All Tablets & Phones. The PDF is 194 MB, best downloaded over Wi-Fi, and after that it needs no internet connection.

CONTENTS:
Maintenance: periodic maintenance schedule, engine oil and filter, spark plugs, timing belt, coolant and fluids.- Petrol engines: EJ204, EJ253 and EJ255 fuel injection, turbocharger and intercooler, cylinder heads, camshafts, pistons and crankshaft.- Diesel engine: EE20 commonrail assembly, fuel injectors, fuel pump, timing chain, vacuum pump, EGR valve, EGR cooler and DPF.- Cooling and lubrication: radiator, main and sub fans, water pump, thermostat and oil pressure system.- Transmissions: 4AT control valve body, TCM and transfer clutch, 5MT single-range and dual-range gear trains, 6MT and clutch.- Driveline: front differential, T-type and VA-type rear differentials, center differential, transfer case and drive shafts.- Chassis: front struts, arms and ball joints, rear trailing links and lateral links, wheel alignment, brakes, VDC and parking brake.- Steering: electric and hydraulic power steering for LHD and RHD.- Climate: heater, A/C compressor, condenser, evaporator and refrigerant charging.- Body and electrics: keyless access, push button start, immobilizer, airbags, lighting, wipers and the complete wiring system.- And Much More…

Special Features:
9,690 pages of Subaru service information in one PDF
8,371 bookmarks and 15,301 clickable cross-references
579 removal and 581 installation procedures
601 DTC procedures in 13 diagnostics chapters
A 1,337 page wiring system chapter with harness and connector locations
Searchable text on 9,142 of the 9,690 pages

Coverage: the foreword names the 2009 model year SH Forester as the applicable model, and the engine sections are written for the EJ204, EJ253, EJ255 and EE20.

Subaru Forester 2009-2013 Power Supply Wiring Diagram PDF Download

Subaru Forester 2009-2013 Diesel Timing Chain PDF Download

Instant Download

Frequently Asked Questions

Which engines are in the 2009-2013 Subaru Forester service manual?
Four boxer engines: the 2.0 litre EJ204 and 2.5 litre EJ253 petrol units, the EJ255 turbo from the 2.5 XT, and the EE20 2.0 litre turbo diesel. The manual gives every engine its own set of chapters, from fuel injection through to engine diagnostics.

Does the Forester repair manual cover the 2.5 XT turbo?
Yes. The EJ255 has its own chapters, including the turbocharger, intercooler and air by-pass valve, the timing belt and a 625 page engine diagnostics section.

Which file format is the Subaru Forester manual in?
It comes as a single PDF with 8,371 bookmarks and clickable contents, so it opens in any PDF reader on a computer, tablet or phone with nothing to install. Zoom into the wiring diagrams, print only the pages you need and keep a copy on each of your devices.

Are wiring diagrams included for the Forester SH?
Yes. A 1,337 page wiring system chapter covers the power supply and ground circuits, charging, starter, push button start, AT control, VDC, A/C, lighting, keyless access, CAN communication and the full time dual-range system, plus harness and connector locations.

Do you have Forester manuals for other years?
Yes. See the Subaru Forester 2003-2008 service manual PDF and the Subaru Forester 2015-2018 service manual PDF. Every other Subaru title is in the Subaru workshop manual range.
